4.3 5 Implement An Access Control Model Testout

Implementing an access control model is a foundational skill for any IT professional pursuing certifications like CompTIA Security+, Network+, or completing courseware such as TestOut Security Pro. In real terms, section 4. 3.5 Implement an Access Control Model in the TestOut curriculum typically challenges students to configure file system permissions, user rights, and group policies to enforce a specific security model—most commonly Discretionary Access Control (DAC), Mandatory Access Control (MAC), or Role-Based Access Control (RBAC).

This article provides a comprehensive walkthrough of the concepts, strategies, and step-by-step methodologies required to successfully implement an access control model in a simulated Windows environment, ensuring you understand the why behind every click.

Understanding the Core Access Control Models

Before diving into the implementation steps, you must identify which model the scenario requires. The configuration steps differ significantly based on the model's philosophy That alone is useful..

1. Discretionary Access Control (DAC)

• Philosophy: The resource owner decides who has access.
• Mechanism: Access Control Lists (ACLs) on files/folders (NTFS permissions).
• Key Characteristic: Flexible but prone to "permission creep" and accidental data leakage.
• TestOut Context: Usually implemented via the Security tab in File Explorer properties or icacls command line.

2. Mandatory Access Control (MAC)

• Philosophy: The system (OS) enforces access based on classification labels (Clearance vs. Classification).
• Mechanism: Sensitivity labels (Top Secret, Secret, Confidential) attached to subjects (users) and objects (files). Users cannot change these labels.
• Key Characteristic: High security, low flexibility. Common in government/military.
• TestOut Context: Often simulated via Dynamic Access Control (DAC) in Windows Server (Central Access Policies) or Linux SELinux/AppArmor labs.

3. Role-Based Access Control (RBAC)

• Philosophy: Access is granted based on the user's role within the organization (Job Function).
• Mechanism: Users $\rightarrow$ Groups (Roles) $\rightarrow$ Permissions.
• Key Characteristic: Scalable, manageable, follows "Least Privilege" and "Separation of Duties."
• TestOut Context: The most common lab requirement. Implemented by creating Security Groups in Active Directory Users and Computers (ADUC), nesting groups (AGDLP/AGUDLP), and assigning permissions to the Group, never the individual user.

4. Attribute-Based Access Control (ABAC)

• Philosophy: Access decisions based on attributes (User: Dept=Finance; Resource: Classification=Financial; Environment: Time=Business Hours).
• Mechanism: Policy engines evaluating claims.
• TestOut Context: Advanced labs utilizing Active Directory Federation Services (AD FS) or Dynamic Access Control Claim Types.

Pre-Implementation Checklist: The "AGDLP" Strategy

In a Windows domain environment (standard for TestOut labs), Microsoft best practice dictates the AGDLP (Account, Global Group, Domain Local Group, Permission) or AGUDLP (adding Universal Groups) strategy. Never assign permissions directly to a user account.

1. A (Account): Create the user accounts.
2. G (Global Group): Create Global Groups representing Roles (e.g., G_HR_Managers, G_IT_Admins). Add User Accounts here.
3. UD (Universal Group - Optional): For multi-domain forests, nest Global Groups into Universal Groups.
4. DL (Domain Local Group): Create Domain Local Groups representing Resource Access (e.g., DL_Folder_Payroll_Modify, DL_Printer_Color_Print). Nest Global/Universal Groups here.
5. P (Permission): Apply the Domain Local Group to the Resource ACL (NTFS/SMB/Printer) with the specific permission level (Read, Write, Modify, Full Control).

Exam Tip: If the lab asks "Why can't the user access the file?Now, ", check Group Nesting: Is the User in the Global Group? Is the Global Group in the Domain Local Group? Does the Domain Local Group have the ACL on the folder?

Step-by-Step Implementation Guide (Windows Server / Client)

The following workflow covers the standard RBAC implementation via Group Policy and NTFS Permissions, which constitutes the bulk of the 4.Day to day, 3. 5 lab objectives Practical, not theoretical..

Phase 1: Organizational Unit (OU) and Group Structure Setup

Open Active Directory Users and Computers (ADUC).

1. Create OUs: Structure OUs by Department or Function (e.g., OU=HR, OU=IT, OU=Finance). This allows targeted Group Policy Object (GPO) linking.
2. Create Global Groups (Roles):
   • Right-click OU $\rightarrow$ New $\rightarrow$ Group.
   • Group Scope: Global.
   • Group Type: Security.
   • Naming Convention: G_<Dept>_<Role> (e.g., G_Finance_Analysts).
3. Populate Global Groups: Add relevant User Accounts to these Global Groups.
4. Create Domain Local Groups (Resources):
   • Create in a dedicated OU=Security Groups or OU=Resource Groups.
   • Group Scope: Domain Local.
   • Group Type: Security.
   • Naming Convention: DL_<Resource>_<Permission> (e.g., DL_Share_Finance_Modify).
5. Nest Groups (The Magic Step): Open the Domain Local Group $\rightarrow$ Members tab $\rightarrow$ Add $\rightarrow$ Select the Global Group.
   • Result: G_Finance_Analysts $\rightarrow$ Member of $\rightarrow$ DL_Share_Finance_Modify.

Phase 2: File System (NTFS) Permission Configuration

handle to the target folder on the File Server (e.g., E:\Data\Finance).

1. Right-click Folder $\rightarrow$ Properties $\rightarrow$ Security tab.
2. Click Advanced $\rightarrow** Disable Inheritance** $\rightarrow$ Convert inherited permissions into explicit permissions on this object. (This isolates the folder for testing).
3. Remove unnecessary default groups (e.g., Users, Authenticated Users) to enforce Least Privilege. Keep SYSTEM, Administrators, CREATOR OWNER.
4. Click Add $\rightarrow$ Select a principal $\rightarrow$ Type the Domain Local Group (DL_Share_Finance_Modify).
5. Set Permissions:
   • For Data Folders: Modify (Read, Write, Delete, Delete Subfolders/Files). Avoid Full Control (prevents users from changing permissions).
   • For Drop Boxes: Write (Create files/folders) + Read (List folder) but No Delete.
   • Apply to: "This folder, subfolders, and files".
6. Click OK $\rightarrow$ OK $\rightarrow$ Apply.

Phase 3: Share Permissions (SMB) Configuration

NTFS secures local and remote access; Share permissions only apply over the network. The most restrictive permission wins.

1. Same Folder Properties $\rightarrow$ Sharing tab $\rightarrow$ Advanced Sharing.
2. Check Share this folder.
3. Permissions button $\rightarrow$ **
